Model | HW-5.0T |
Working weight (kg) | 5000 |
Engine model | CF490B |
Engine power (kw) | 40 |
Walking speed (km/h) | 1-3-5-12km/h |
Gradeability (%) | 30 |
Vibration frequency (Hz) | 46 |
Dimensions (mm) | 4450*1650*2650 |
Steel wheel size (mm) | φ1000*1450 |
Drive method | Mechanical gear---4 gear high and low speed |
The main application of this equipment is the compaction and leveling of ditches, roads, and sports fields, and it can also be used for compacting asphalt pavement.
1. It has a small working radius, allowing it to operate in narrow areas, making it suitable for trench backfilling.
2. It is equipped with a HONDA gasoline engine or a well-known diesel engine, delivering superior performance and easy starting.
3. It features an imported hydraulic drive unit from an internationally renowned brand, offering stepless speed change, forward and backward movement, and hydraulic steering.
4. The motor can be started, and the equipment has hydraulic vibration, ensuring easy and convenient operation.
Quote now for the best price.
Whether you need a standard machine or a custom solution, our engineers are ready to assist. Please provide as much detail as possible so we can quote accurately and quickly.
